Description
Using digital ultrasonic technology, our Sonix® ultrasonic meters are designed with no moving parts, virtually eliminating the cost of repairs. These meters retain their calibration. They also provide alerts for tampering and for malfunctions. Their compact design affords flexible installation options.
The electronic platform allows you to include automatic meter reading more cost-effectively and to upgrade the meter with the latest options while it is still in service.
For remote data collection and storage, Sonix meters feature a pulse output option. The two-wire pulse output enables them to send data to any Form A pulse accumulation hardware. The combination of Sonix meters and remote data collection devices provide a sound solution for today’s growing need for measurement accuracy and lowest total cost of ownership.
Product Features
- Fixed factor pressure compensation
- 2000 cfh max capacity at 1/2" wc drop / 3000 cfh max capacity with 1.3" wc drop
- Max pressure 60 psi
- 2" FF flange connection
- 12.6" end-to-end length
- Warranty – 15 years meter; 10 years battery
- Diagnostics – Meter health, tampering, reverse flow, and air in meter
- Temperature Compensation – Internal thermistor
- Pressure Compensation – Optional internal transducer or fixed factor
- Proof Verification – Compatible with rotary transfer provers
- Data Logging – Hourly for 60 days
